Supermicro Storage SuperServer SSG-631E-E1CR16H
3U front-loading storage server with 16 hot-swap 3.5″ SAS/SATA bays (SAS hardware RAID) and PCIe 5.0
Key Applications
Enterprise Server, iSCSI SAN, HPC, Data Center, Database Processing & Storage, Corporate Database, Appliance Optimized Storage Building Blocks,
Key Features
Dual Socket E (LGA-4677) 5th/4th Gen Intel® Xeon® Scalable processors;
Up to 4TB 3DS ECC RDIMM, DDR5-5600MT/s(1DPC) in 16 DIMM slots;
2x 10 GbE onboard via Broadcom BCM57416 1x GbE Dedicated LAN for server remote management: IPMI 2.0 / KVM over LAN / Media over LAN;
16x 3.5″/2.5″ Hot-swap SAS3/SATA3 drives, 2x Rear 2.5″ SATA Slots, 2x NVMe M.2 (form factor: 2280 and 22110);
5x 8cm hot-swap counter-rotate redundant PWM cooling fans;
1200W Redundant Power Supplies Titanium Level (96%);
HW RAID support via Broadcom® 3908;
Additional information
| Form Factor | 3U Rackmount Enclosure: (17.2" x 5.2" x 25.5") Package: (27" x 13" x 35") |
|---|---|
| Processor | Dual Socket E (LGA-4677) 5th Gen Intel® Xeon® / 4th Gen Intel® Xeon® Scalable processors |
| System Memory | Slot Count: 16 DIMM slots Max Memory (1DPC): Up to 4TB 5600MT/s ECC DDR5 RDIMM |
| Drive Bays Configuration | Default: Total 18 bay(s) 16 front hot-swap 3.5" SAS/SATA drive bay(s) 2 rear hot-swap 2.5" SATA drive bay(s) M.2: 2 M.2 PCIe 4.0 x2 NVMe slot(s) (M-key 2280/22110) Peripheral Bays: 1 slim DVD bay(s) (optional) |
| Expansion Slots | Default 4 PCIe 5.0 x16 (in x16) FHHL slot(s) 2 PCIe 5.0 x8 (in x8) FH/10.5"L slot(s) |
| On-Board Devices | Chipset: Intel® C741 Network Connectivity: 2 RJ45 10GbE with Broadcom® BCM57416 |
| Input / Output | LAN: 1 RJ45 1 GbE Dedicated IPMI LAN port(s) 2 RJ45 10 GbE LAN port(s) (Broadcom® BCM57416) (IPMI shared on LAN port 1) USB: 4 USB 3.0 port(s) (rear) Video: 1 VGA port(s) (Rear) Serial: 1 COM port(s) (Rear) TPM: 1 TPM header |
| System Cooling | Fans: 5 Heavy Duty 8cm Fan(s) |
| Power Supply | 2x 1200W Redundant Titanium Level (96%) Hot-plug power supplies |
| System BIOS | BIOS Type: AMI 32MB SPI Flash EEPROM |
| Management | SuperCloud Composer; Supermicro Server Manager (SSM); Supermicro Update Manager (SUM); Supermicro SuperDoctor® 5 (SD5); Super Diagnostics Offline (SDO); Supermicro Thin-Agent Service (TAS); SuperServer Automation Assistant (SAA) New! |
| PC Health Monitoring | CPU: Monitors for CPU Cores, Chipset Voltages, Memory 7+1 Phase-switching voltage regulator FAN: Fans with tachometer monitoring Status monitor for speed control Pulse Width Modulated (PWM) fan connectors Temperature: Monitoring for CPU and chassis environment Thermal Control for fan connectors |
| Dimensions and Weight | Weight: Gross Weight: 79 lbs (48 kg) Available Color: Silver |
| Operating Environment | RoHS Compliant Operating Temperature: 10°C ~ 35°C (50°F ~ 95°F) Non-operating Temperature: -40°C to 60°C (-40°F to 140°F) Operating Relative Humidity: 8% to 90% (Non-Condensing) Non-operating Relative Humidity: 5% to 95% (Non-Condensing) |
| Motherboard | Super X13DEI-T |
| Chassis | CSE-836BTS-R1K23BP2 |
