ASUS RS500A-E12-RS12U AMD EPYC™ 9004 single-processor 1U Rack Server

ASUS RS500A-E12-RS12U AMD EPYC™ 9004 single-processor 1U Rack Server

SKU: RS500A-E12-RS12U Categories: Rack Servers, Servers & Storage

Get a Quote

Description
Additional information
Reviews (0)

Description

AMD EPYC™ 9004 single-processor 1U server that supports up to 24 DIMM, 16 NVMe, three PCIe® 5.0 slots, two M.2, OCP 3.0, two single-slot GPUs, and ASUS ASMB11-iKVM

Key Features

Powerful performance:Powered by AMD EPYC 9004 processors with 128 Zen 4c cores, 12-channel, up to 4800 MHz DDR5 and support for a maximum TDP of up to 400 watts
Scale-up storage and expansion design: Up to 12 all-flash NVMe drives on the front panel, 4 NVMe in middle bay, and 3 PCIe 5.0 slots for higher bandwidth and system upgrade
Flexible networking module design:On-board LAN module, and OCP 3.0 module with PCIe 5.0 slot in rear panel for faster connectivity
Advanced air cooling solution: Features enhanced volume air cooling (EVAC) heatsink for processors with higher TDP
Enhanced IT-infrastructure management:ASUS ASMB11-iKVM remote control with ASPEED AST2600, ASUS Control Center IT management software and hardware-level Root-of-Trust solution
Ideal for AI and HPC workloads:Up to two single-slot GPUs.

Additional information

Processor / System Bus	1 x Socket SP5 (LGA 6096) 4th Generation AMD EPYC Processors with AMD 3D V-Cache technology AMD EPYC™ 9004 Series Processors (Air cool with EVAC up to 400W)
Memory	24 x DIMM slots DDR5 4800/4400/4000/3600 RDIMM/ 3DS RDIMM 1DPC up to 4800 2DPC up to 4000(1R+1R) 2DPC up to 3600(1R+2R)/ (2R+2R) Maximum 6144GB * Refer to support page for more information
Expansion Slots	Up to 3 PCIe Gen5 slots + 1 OCP3.0 1 x PCIe x16 slot (Gen5 x16 link, FH, HL) 1 x PCIe x16 slot (Gen5 x16 link, LP, HL) 1 x PCIe x16 slot (Gen5 x8 link, LP, HL) 1 x OCP3.0 socket (Gen5 x16 link)
Storage	Storage Controller : CPU Integrated Optional kits Controller : ASUS PIKE II 3008-8i 8-port SAS 12G HBA card
Drive Bays	Front bays: 12 x 2.5” Hot-swap Storage Bays 12 x SATA/SAS/NVME Mid storage bays SKU support up to 16NVMe/SATA/SAS** SAS support only from optional SAS HBA/RAID card *Internal Storage Bays is designated as build-to-order only, owing to quality or installation concerns. 2 x M.2 connectors
Networking	1 x Dual Port Intel I350-AM2 GbE LAN Controller 1 x Management Port
Graphic	Up to 2 single-slot GPU cards *Internal Storage Bays SKU only support 1 single-slot GPU card
Multi-GPU Support	Please find the latest GPU support from https://servers.asus.com/support/GPU
Rear I/O Ports	2 x USB 3.2 Gen1 ports 1 x VGA port 1 x Management port 2 x 1GbE LAN ports
Switch/LED	Front: 1 x Power Button/LED 1 x Location Button/LED 1 x Message LED LAN 1-2 LED Rear: 1 x Port80 LED (Q-Code) 1 x Power Button/LED 1 x Location Button/LED 1 x Message LED
OS Support	Please find the latest OS support from: https://servers.asus.com/support/os
Management Solution	ASUS Control Center ASUS ASMB11-iKVM (on-board)
Regulatory Compliance	BSMI, CB, CE, RCM, FCC(Class A)
Dimensions	842.5mm x 449mm x 43.85mm (1U) 33.17" x 17.68" x 1.73"
Form Factor	1U
Weight	(approximate) Net Weight: 14.16 kg Gross Weight: 19.16 kg
Power Supply	1+1 Redundant 1600W 80 PLUS Titanium Power Supply 1+1 Redundant 1600W/1200W 80 PLUS Platinum Power Supply
Environment	Operating temperature: 10°C – 35°C Non operating temperature: -40°C – 70°C Non operating humidity: 20% – 90% (Non condensing) Note： Operating Temperature based on configurations
